5MP Turret TVI, CVI, AHD, CVBS Camera – 2.8mm Fixed Lens – Color Night Vision – IP67 Rated

Name: 5MP Turret TVI, CVI, AHD, CVBS Camera - 2.8mm Fixed Lens - Color Night Vision - IP67 Rated
SKU: RTC-AC346-FDF-2GY
Price: 156.00 CAD
Availability: InStock

Add to wishlist

TVI Cameras 5MP SKU: RTC-AC346-FDF-2GY

This 5MP color night vision, indoor/outdoor, TVI based turret camera features maximum light gathering capability to provide full color imaging in extremely dark settings. The camera comes with a 2.8mm fixed lens which delivers a 99.7° horizontal field of view. Its maximum resolution is 2560 x 1944. Using TurboHD technology, the high definition video analog signal can be sent over existing coaxial cable, eliminating the need to run new cables. Its housing is IP67 rated for outdoor use.

Add to wishlist

Description

Features

24/7 Full Time Color
5MP High Performance CMOS Sensor
Up to 2560 x 1944 Resolution
2.8 mm Fixed Lens
3D DNR, OSD Menu (Up the Coax)
Up to 65 ft (20 m) White Light Range
130 dB True WDR
Multiprotocol Output: TVI/AHD/CVI/CVBS
IP67

Application

Specifications

Camera
Image Sensor	5.0 MP CMOS image sensor
Signal System	NTSC
Frame Rate	TVI: 5 MP @ 20 fps, 4 MP @ 30 fps, 4 MP @ 25 fps, 1080p @ 30 fps, 1080p @ 25 fps CVI: 4 MP @ 30 fps, 4 MP @ 25 fps AHD: 5 MP @ 20 fps, 4 MP @ 30 fps, 4 MP @ 25 fps CVBS: NTSC
Resolution	2560 (H) x 1944 (V)
Minimum Illumination	Color: 0.0005 lux @ (ƒ/1.0, AGC on), 0 lux with white light
Shutter Time	1/30 s to 1/50,000 s
Lens	2.8 mm fixed focal lens
Field of View	Horizontal FOV: 99.7°, vertical FOV: 72°, diagonal FOV: 139.8°
Lens Mount	M16
Strobe Light Alarm	Yes
Day and Night	Color
Angle Adjustment	Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360°
WDR	130 dB
Menu
White Light	Auto/off
Image Mode	STD/HIGH SAT
AGC	Supported
Day and Night Mode	Color
White Balance	Auto/manual
Auto Exposure Mode	WDR/BLC/HLC/Global/ HLS/Anti-Banding
Motion Detection	4 programmable areas
Noise Reduction	3D DNR
Language	English
Functions	Brightness, sharpness, mirror, smart light
Interface
Video Output	1 HD analog output
Switch Button	TVI/AHD/CVI/CVBS
General
Operating Conditions	-40° F to 140° F (-40° C to 60° C), humidity: 90% or less (non-condensation)
Power Supply	12 VDC ± 25%
Power Consumption	Maximum 3.5 W
Ingress Protection	IP67
Material	Enclosure: Plastic Main Body: Metal
White Light Range	Up to 65 ft (20 m)
Communication	Up the coax, Protocol: UTC-C (TVI output)
Dimensions	Ø4.32″ x 3.37″ (Ø109.82 mm x 85.56 mm)
Weight	Approximately 0.77 lbs (350 g)

Downloads

Web Portal Remote Access
Register/login with your Guarding Vision account for access to all devices in your account remotely from the browser. Supports Internet Explorer 8+, Chrome 41.0 to 44, Firefox 30.0 to 51 and Safari 8.0 to 11

Guarding vision Android app
Supports Android 4.1 and up

Guarding vision iOS app
Supports iOS 8.0 or later. Compatible with iPhone, iPad and iPod touch

Warranty

All cameras and hard drives sold by RTC Electronics come with a 3-year warranty ensuring them free from manufacturing and material flaws. The original buyer who provides evidence of purchase is eligible for this warranty. This warranty does not cover any product failure or damage resulting from events outside RTC Electronics’ control, such as misuse, negligence, or accidental damage, inaccurate application or installation, alterations, Act of God, or ordinary wear and tear. Any removal or installation expenses are not the responsibility of RTC Electronics. Cables’ full and exclusive obligation under this warranty is to, in our exclusive discretion, either repair or replace the defective item. RTC Electronics disclaims any additional warranties, express or implied, including the implied warranty of merchantability. RTC Electronics won’t be held responsible for any losses, including lost or anticipated profits, delays, consequential damages, or other, unique damages.
