Description
The BT-12V-12AF2 is a 12 volt, 12 amp sealed lead acid, non-spillable, rechargeable battery. This battery is typically used as a replacement battery in UPS systems, security alarm systems or security lighting applications.
The BT-12V-12AF2 is a 12 volt, 12 amp sealed lead acid, non-spillable, rechargeable battery. This battery is typically used as a replacement battery in UPS systems, security alarm systems or security lighting applications.
The BT-12V-12AF2 is a 12 volt, 12 amp sealed lead acid, non-spillable, rechargeable battery. This battery is typically used as a replacement battery in UPS systems, security alarm systems or security lighting applications.
Physical Characteristics | |
---|---|
Type | UPS Replacement |
Voltage | 12V |
Amps | 12A |
Terminal Type | F2 |
Tab Size | 0.25 inch |
Container Material | ABS(UL-94HB) |
Length | 3.9 inches [98mm] |
Width | 6 inches [151mm] |
Height | 3.7 inches [94mm] |
Operating Temperature | 25±3℃ (77±5℉ ) |
Compatible Terminal Adapter | |
BT-ADT2T1 | Battery terminal adapter F2 female (0.25”) to F1 male (0.1875”) |
Performance | |
Internal Resistance | Approx.90mΩ |
Max. Discharge Current | 117A(5S) |
Rated Capacity | 12.0AH (20hr, 1.75V/cell,25℃/77℉) 11.5AH (10hr, 1.75V/cell,25℃/77℉) 11.0AH (5hr, 1.75V/cell,25℃/77℉) 10.3AH (3hr, 1.75V/cell,25℃/77℉) 7.75AH (1hr, 1.75V/cell,25℃/77℉) |
Cycle Use | Charge Current Less Than 0.25CA 14.1V~14.7V@25℃(77℉)Temp. Coefficient -30mV/℃ |
Floating Use | No limit on Initial Charging Current Voltage 13.5V~13.8V@25℃(77℉)Temp. Coefficient -20mV/℃ |
Capacity affected by Temperature | 40°C 103% 25°C 100% 0°C 86% -15°C 65% |
Self-discharge | 3 month Remaining capacity: 91% 6 month Remaining capacity:82% 12 month Remaining capacity:65% |
Packaging Information | |
Product Weight | 8.2 lbs [3.7kg] |
Warranty Information | |
Warranty | 6 Months |
Compatibility Information | |
Model Number | APC Back-UPS BK650 APC Back-UPS BK650MC APC Back-UPS BK650MUC APC Back-UPS BK650X06 APC Back-UPS BP650S APC Back-UPS BP650IPNP APC Back-UPS BP650PNP APC Back-UPS BP650S APC Back-UPS BP650SUS APC Smart-UPS SU620NET APC Smart-UPS SU650 APC Smart-UPS SUVS650 Belkin UPS S6C500-USB Exide NetUPS 700 Powerware UPS 5105-700 |
