Description
The BT-12V-5AF2 is a 12 volt, 5 amp sealed lead acid, non-spillable, rechargeable battery. This battery is typically used as a replacement battery in UPS systems, security alarm systems or security lighting applications.
The BT-12V-5AF2 is a 12 volt, 5 amp sealed lead acid, non-spillable, rechargeable battery. This battery is typically used as a replacement battery in UPS systems, security alarm systems or security lighting applications.
The BT-12V-5AF2 is a 12 volt, 5 amp sealed lead acid, non-spillable, rechargeable battery. This battery is typically used as a replacement battery in UPS systems, security alarm systems or security lighting applications.
Physical Characteristics | |
---|---|
Type | UPS Replacement |
Voltage | 12V |
Amps | 5A |
Terminal Type | F2 |
Tab Size | 0.25 inch |
Container Material | ABS(UL-94HB) |
Length | 2.8 inches [70mm] |
Width | 3.5 inches [90mm] |
Height | 4 inches [102mm] |
Operating Temperature | 25±3℃ (77±5℉ ) |
Compatible Terminal Adapter | |
BT-ADT2T1 | Battery terminal adapter F2 female (0.25”) to F1 male (0.1875”) |
Performance | |
Internal Resistance | Approx.45mΩ |
Max. Discharge Current | 75A(5S) |
Rated Capacity | 5.00AH (20hr, 1.75V/cell,25℃/77℉) 4.82AH (10hr, 1.75V/cell,25℃/77℉) 4.73AH (5hr, 1.75V/cell,25℃/77℉) 4.29AH (3hr, 1.75V/cell,25℃/77℉) 3.23AH (1hr, 1.75V/cell,25℃/77℉) |
Cycle Use | Charge Current Less Than 0.25CA 14.1V~14.7V@25℃(77℉)Temp. Coefficient -30mV/℃ |
Floating Use | No limit on Initial Charging Current Voltage 13.5V~13.8V@25℃(77℉)Temp. Coefficient -20mV/℃ |
Capacity affected by Temperature | 40°C 103% 25°C 100% 0°C 86% -15°C 65% |
Self-discharge | 3 month Remaining capacity: 91% 6 month Remaining capacity:82% 12 month Remaining capacity:65% |
Packaging Information | |
Product Weight | 3.75 lbs [1.7kg] |
Warranty Information | |
Warranty | 6 Months |
Compatibility Information | |
Model Number | Belkin UPS F6350 Belkin UPS F6C325 Belkin UPS F6C550-AVR Belkin UPS F6C550FCAVR Belkin UPS F6C550ODMAVR Belkin UPS F6C550SPAVR Belkin UPS F6H350 Belkin UPS F6H375-USB Belkin UPS F6H375ODMUSB Belkin UPS F6H375SPUSB Belkin UPS F6H500 Belkin UPS F6H500-USB Powerware UPS 3105-350 Powerware UPS 3105-500 Powerware UPS 5110-350 Powerware UPS 5110-500 |
