60m HDMI Extender with Audio
This HDMI Extender offers top-tier resolution of up to 1080P/60Hz, enabling long-distance transmission of up to 60 meters.
Description
This HDMI Extender offers top-tier resolution of up to 1080P/60Hz, enabling long-distance transmission of up to 60 meters. It includes 3.5mm left and right channel audio output, boasting low power consumption and operating at low temperatures while ensuring high safety standards. Additionally, it supports infrared IR control, USB mouse, and keyboard extension. The CAT5e or CAT6 cable length between the receiving and transmitting ends can reach up to 60 meters.
| Feature | Details |
|---|---|
| Product Name | KVM Single Network Extender |
| HDMI Input | 1080p/1080i/720p/576p/576i/480p/480i |
| HDMI Output | 1080p/1080i/720p/576p/576i/480p/480i |
| Maximum Transmission Bandwidth | 150MHz |
| Maximum Transmission Rate | 4.5Gbps |
| Input Video Signal | 0.5~1.5 Volts p-p |
| Output DDC Signal | 5 Volts p-p (TTL) |
| Input HDMI Cable Length | ≤ 10m AWG26 Standard HDMI Cable |
| Output HDMI Cable Length | ≤ 15m AWG26 Standard HDMI Cable |
| Maximum Working Current (TX/RX) | 300mA |
| Power Specification | Input: AC (50Hz, 60Hz) 100V-240V Output: DC 5V/1A |
| Operating Temperature Range | -15 to +45 Celsius |
| Operating Humidity Range | 5 to 90 RH (No Condensation) |
| Application Scenarios | Audio-visual conferences, command and control centers, ticketing platforms, home theaters, multimedia teaching, conference systems, etc. |
| Plug Type | US Plug (Applicable to Canada, India, Mexico, Thailand, Taiwan, the United States, the Philippines, etc.) EU Plug (Applicable to Indonesia, Germany, France, Spain, Italy, etc.) |
