HIKVISION – 8-Port Gigabit 110W PoE Switch + 2-Port RJ45 and SFP Uplink – Desktop/Wall Mount – Unmanaged – IEEE 802.3at/af
This 8-port switch is a gigabit Ethernet switch, providing 8 Gigabit PoE ports, one 10/100/1000 Mbps RJ45 port, and one 10/100/1000 Mbps SFP fiber optical port. The switches provide advanced PoE technology and connect other devices with high performance. The Gigabit ports also guarantee stable transmission of data.
Description
This 8-port switch is a gigabit Ethernet switch, providing 8 Gigabit PoE ports, one 10/100/1000 Mbps RJ45 port, and one 10/100/1000 Mbps SFP fiber optical port. The switches provide advanced PoE technology and connect other devices with high performance. The Gigabit ports also guarantee stable transmission of data.
Features
- 8 x Gigabit PoE ports
- 1 x Gigabit RJ45 uplink port
- 1 x Gigabit SFP fiber optical uplink port
- IEEE 802.3at/af standard
- IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, and IEEE 802.3z standard
- 6 KV surge protection for PoE ports
- PoE power management
- Gigabit network access
- Wire-speed forwarding and non-blocking design
- Store-and-forward switching
- Solid high-strength metal shell
- Reliable fan-free design
Application
|
Physical Characteristics
|
||||
|---|---|---|---|---|
| Dimensions | 217.6 x 27.8 x 108.55 mm (8.6 x 1.1 x 4.3 inches) | |||
| Shell | Metal Material, Fan-Free Design | |||
| Operating Temperature | -10°C to 55°C | |||
| Storage Temperature | -40°C to 85°C | |||
| Operating Humidity / Storage Humidity |
5% to 95% (no condensation) | |||
| Power Supply | 48 VDC, 1.35 A | |||
| Power Consumption (Idle) | 5 W | |||
| Ports | 8 x Gigabit PoE ports | |||
| Uplink Ports | 1 x Gigabit RJ45 port 1 x Gigabit SFP fiber optical port |
|||
| Port Type | RJ45 port, Full duplex, MDI/MDI-X adaptive | |||
| PoE Power Supply | PoE Standard: IEEE 802.3af, IEEE 802.3at PoE Power Pin: Support 4-core power supply, and Ethernet cable 1/2/3/6 provide power supply. PoE Port: Ports 1 to 8 Maximum Port Power: 30 W PoE Power Budget: 110 W Maximum Power Consumption: 120 W |
|||
|
Performance
|
||||
| Network Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z | |||
| MAC Address Table | 4K | |||
| Forwarding Mode | Store-and-forward switching | |||
| Switch Type | Layer 2 | |||
| Switching Capacity | 20 Gbps | |||
| Packet Forwarding Rate | 14.88 Mpps | |||
| Internal Cache | 1.5 Mbits | |||
|
SFP Compatibility
|
||||
| TR-SFP-1G-LXG | 1000base-LX SFP 1310nm SM LC Transceiver, 10km | |||
| TR-SFP-1G-SXG | 1000base-SX SFP 850nm MM LC Transceiver, 500m | |||
|
Environmental
|
||||
| RoHS | Yes | |||
|
Packaging Information
|
||||
| Package Quantity | 1 | |||
| Product Weight | 3.09 lbs [1.4kg] | |||
Warranty
2-YEAR WARRANTY
RTC Electronics offers a 2-year warranty on NVR/DVR’s and network switches to be free from defects in material and workmanship.
This warranty is available to the original purchaser with proof of purchase. This warranty does not apply to any damage or product failure that is caused beyond Infinite Cables’ control, including but not limited to, misuse, neglect, accidental damage, improper installation or application, alteration, acts of God, or normal wear and tear. Infinite Cables is not responsible for any costs of removal or installation. Infinite Cables’ sole and exclusive obligation under this warranty shall be limited to repair or replacement of the defective item at our discretion.
Infinite Cables makes no other warranties expressed or implied including without limitation and warranty of fitness for a particular purpose. Infinite Cables will not be liable for damages of any kind including lost or anticipated profits, delay, consequential or special damages.
